Magnum 12V / 24V Multi-Stage Smart Charger - TE40226

Diagnoses, recovers, and maintains large vehicle and marine batteries. The Magnum TE40226 automatically selects the appropriate charging voltage for 12V or 24V systems. Features an IP65 housing to block dust and splashes, alongside a 16V boost function for severely discharged cells.

Features

• Auto-Selection - Detects the battery voltage and adjusts the charging profile.
• Battery Boost Mode - Delivers 16V / 1.5A to recover severely discharged batteries.
• IP65 Protection - Resists dust and liquid splashes in the shop or garage.
• LED Error Display - Indicates faults and warns the operator with an audible beep.
• Spark Proof - Prevents arcing during terminal connection.

Specifications

• Voltage Output: 12V / 24V
• Charging Current (12V): 4A / 6A
• Charging Current (24V): 3A
• Boost Mode: 16V / 1.5A
• Protection Rating: IP65
• Supplier Part Number: TE40226
• KMS Product Code: MAG-TE40226

Common Shop Applications

• Charging heavy-duty 24V equipment
• Recovering deeply discharged automotive batteries
• Maintaining marine and RV electrical systems

Recommended Shop Add-Ons

• Battery Load Tester
• Jumper Cables
• Dielectric Grease

Frequently Asked Questions

Q: Will this charge a 24V system? A: Yes, it automatically selects between 12V and 24V outputs.

Q: Can it recover a dead battery? A: It features a 16V / 1.5A boost mode specifically for severely discharged batteries.
